12.1-Inch Industrial-Grade Capacitive Touch Panel & LCM — Large-Screen Precision, Built for Demanding Environments

12.1-Inch Industrial-Grade Capacitive Touch Panel & LCM — Large-Screen Precision, Built for Demanding Environments

12.1-inch industrial-grade capacitive touch display combines an original BOE high-brightness LCD module with a G+G (Glass + Glass) capacitive touch panel, powered by dual industrial-grade GOODIX touch controllers for unparalleled precision and responsiveness. Designed to meet the stringent demands of medical devices and industrial automation, it delivers stable performance, excellent visibility, and long-term durability even under extreme conditions.

Core Technical Specifications

touchscreen Specifications

• Overall Dimensions: 275.6 mm × 177.8 mm (R8*4 rounded corners)

• Viewable Window Size: 261.72 mm × 163.8 mm

• Cover Glass Thickness: 0.7 mm

• Structure: G+G (Glass + Glass)

• Surface Hardness: 6H ± 1, scratch-resistant

• Touch IC Brand: GOODIX

• Touch IC Model: GT928 + 8013 dual-controller solution

• Interface: IIC + USB

LCD Specifications

• Brand: BOE

• Model: EV121WXM-N12

• Resolution: 1280 × 800 (WXGA)

• Brightness: 500 cd/m² (high visibility in bright environments)

• Interface: LVDS

• Color Gamut: 72% NTSC

Certifications & Compliance

• Passed medical-grade EMC (Electromagnetic Compatibility) and EFT (Electrical Fast Transient) testing

• 100% compliant with RoHS environmental standards

• Industrial-grade touch chip design for long-term stability and reliability

Product Advantages

1. Large-Format, High-Resolution Display

• With a 12.1-inch screen and 1280×800 resolution, it delivers crystal-clear images and smooth text rendering, perfect for information-dense interfaces such as medical monitoring, industrial control dashboards, and data visualization.

2. Industrial-Grade Touch Performance

• Dual GOODIX controllers (GT928 + 8013) ensure precise, fast, and stable touch response even in environments with high electromagnetic interference.

• Multi-interface design (IIC + USB) enhances flexibility for integration with different system architectures.

3. Durable & Reliable Construction

• G+G glass structure ensures durability and scratch resistance with a 6H hardness rating, while maintaining high transparency for excellent display clarity.

• Engineered to withstand frequent and intensive touch operations without degradation in performance.

4. High Visibility in Bright Environments

• Equipped with an original BOE 500 cd/m² LCD module, ensuring vivid, true-to-life colors and clear visibility even under strong lighting conditions.

5. Wide Temperature Tolerance

• Designed for -20°C to 70°C operating range and -30°C to 80°C storage range, making it suitable for a variety of indoor and outdoor industrial applications.

Typical Application Scenarios

Medical Industry

• Patient monitoring systems

• Surgical navigation interfaces

• Diagnostic imaging control panels

Industrial Control

• Human-Machine Interfaces (HMI)

• Automated production line control consoles

• Test and measurement systems

Transportation & Public Information

• Passenger information systems

• Ticketing and kiosk solutions

• Navigation and control displays in vehicles or vessels

Summary

12.1-inch industrial capacitive touch display is a perfect balance of large display real estate, high brightness visibility, and industrial-grade durability. Backed by BOE’s high-quality LCD technology and GOODIX advanced touch solutions, it is purpose-built for mission-critical medical and industrial applications where reliability, accuracy, and clarity cannot be compromised.

This is more than just a display — it’s a professional-grade user interface solution ready to power the next generation of intelligent equipment.
