4.3-Inch 800×480 IPS TFT LCD with TTL RGB Interface

4.3-Inch 800×480 IPS TFT LCD with TTL RGB Interface

Mass Production Medical Display Solution | Customized by DINGTouch

In modern medical equipment, display performance directly impacts operational accuracy, user experience, and clinical efficiency. DINGTouch presents a 4.3-inch 800×480 IPS TFT LCD module with TTL RGB interface, specifically engineered for medical devices requiring stable mass production, long lifecycle support, and flexible customization.

Product Overview

This 4.3-inch TFT LCD module combines IPS wide-view technology with a highly compatible RGB (TTL) interface, making it ideal for embedded medical systems such as patient monitors, portable diagnostic equipment, infusion pumps, and handheld analyzers.

Its compact structure and stable signal transmission ensure seamless integration into various healthcare control systems.

Core Specifications

• Display Size: 4.3" TFT LCD

• Panel Type: IPS (In-Plane Switching)

• Resolution: 800 × 480 (WVGA)

• Interface: TTL RGB (24-bit parallel)

• Outline Dimension: 105.5 (W) × 67.1 (H) × 3.0 (D) mm

• Active Area: 95.04 (W) × 53.856 (H) mm

• Production Status: Stable Mass Production

Technical Advantages for Medical Applications

1. IPS Wide Viewing Angle Technology

• Up to 178° viewing angle

• Superior color consistency

• Clear data visualization from multiple positions

2. High-Resolution WVGA Display

• 800×480 resolution ensures detailed waveform, parameter, and UI rendering

• Ideal for displaying vital signs, medical graphics, and control dashboards

3. Stable TTL RGB Interface

• Strong compatibility with MCU and embedded systems

• Reliable parallel data transmission

• Easy integration into existing hardware platforms

4. Compact & Slim Structure

• 3.0 mm module thickness

• Space-saving design for handheld or compact medical devices

5. Long-Term Supply & Lifecycle Support

• Stable production line

• Strict quality control

• Medical-grade reliability

DINGTouch Personalized Custom Touch Screen Solutions

As a professional manufacturer with over 10 years of experience in touch display technology, DINGTouch provides full customization services to meet the evolving needs of medical equipment manufacturers.

1. Touch Panel Customization (PCAP)

We offer multiple projected capacitive touch structures:

• G+G (Glass + Glass)

• G+F+F (Glass + Film + Film)

• Film-Film ultra-thin solutions

Customization options include:

✔ Multi-touch (2–10 points)
✔ Glove touch support
✔ Waterproof touch
✔ EMI/ESD enhanced design
✔ Optical bonding (OCA / OCR)
✔ Anti-glare (AG) / Anti-reflective (AR) / Anti-fingerprint (AF) coating

2. Interface Customization

Besides TTL RGB, DINGTouch supports:

• MIPI DSI

• LVDS

• SPI

• HDMI (with driver board)

• USB touch interface

We assist in selecting the optimal interface based on your motherboard and system architecture.

3. Brightness & Backlight Customization

• Standard brightness: 300–500 nits

• High brightness: 800–1000+ nits

• Adjustable backlight control

• Long lifespan LED backlight

Suitable for indoor clinical rooms or high-ambient-light environments.

4. Cover Glass Customization

• Thickness: 0.7mm – 6mm

• Silk printing (logo / medical symbols)

• Custom shape & irregular cutouts

• IK impact-resistant design

• Chemically strengthened glass

5. Environmental & Reliability Enhancement

• Wide temperature range solutions

• EMC/EMI shielding design

• Medical-grade reliability validation

• Long-term stable operation

Typical Medical Applications

• Patient monitoring systems

• Portable ultrasound devices

• Infusion pump displays

• ECG / Vital sign monitors

• Diagnostic analyzers

• Rehabilitation therapy equipment

Why Choose DINGTouch?

✔ Over 10 years of touch display R&D and manufacturing experience
✔ Complete in-house customization capability
✔ Stable mass production capacity
✔ Fast sampling and engineering support
✔ Long-term supply assurance

DINGTouch is committed to delivering high-performance, reliable, and customizable TFT LCD touch display solutions tailored to medical industry requirements.

Ready to Build Your Outdoor Display Solution?

Get in touch with us at sales@szdingtouch.com. Our expert engineers will help you design a cost-effective, tailored solution to meet your project’s exact specifications.

DINGTouch :Committed to continuous innovation and improvement of product quality to meet customers' high requirements and expectations.

DINGTouch is a manufacturer that provides high quality touch screen panels. Focus on the design, manufacturing and sales of touch screen panels, and are committed to providing customized solutions that satisfy customers.

DINGTouch: In the process of customizing touch screen panels, we focus on close cooperation and communication with customers. Understanding customers' needs and providing customized solutions will meet customers' individual needs. The company's products are favored by customers for their high quality and reliability, and provide them with the best touchscreen panel solutions.

At DINGTOUCH, we are the world's leading touchscreen manufacturer, helping businesses around the world take advantage of this exciting technology. For more information, please visit the home page now.
Find the DINGTouch technical team to achieve the success of your company's new project.

How to choose touch screen customization?

DINGTouch is a company specializing in the R&D and production of touch screen technology, headquartered in Shenzhen, China. As a professional touch screen supplier, DINGTouch is committed to providing high-quality, stable and reliable touch screen products to meet the diverse needs of customers. We continue to carry out technological innovation and product optimization to ensure that its touch screen products have good sensitivity, accuracy and durability.

In addition to the products themselves, we also focus on cooperation and communication with customers, and are committed to providing customized solutions and excellent after-sales services. Through continuous efforts to improve product quality and customer satisfaction, we have established a good reputation in the touchscreen industry and won widespread market recognition.

What DINGTOUCH can do:

• PCAP  maximum size 65”

• Multi-touch (Touch screen can be customized to your needs.)

• Optical bonding service/air bonding

• LCD interface: HDMI/RGB/MIPI/LVDS/EDP, etc.

• PCAP interface: IIC/USB interface

• CTP can customize the cover glass surface treatment process AG (anti-glare), AR (anti-reflection), AF (anti-fingerprint), waterproof, and glove touch

• Supports 0.55 mm-12 mm coverslip touch.

• Support operating temperature: -40℃-90℃.

Dingtouch Industrial Capacitive Touch Screen Manufacturer

In conclusion, Dingtouch as a professional touch screen manufacturer with more than 10 years touch screen experience.We have many capacitive touch screen. Such as5  inch touch screen,7 inch touch screen,10.1inch touch screen,15 inch touch screen,15.6 inch touch screen,17 inch touch screen,18.5 inch touch screen,19 inch touch screen,21.5 inch touch screen,32 inch touch screen, However, we also welcome to customize your own touch screen . Contact our team today to learn what capacitive touch screen are best for our retail business needs.
