15-Inch 1024×768 TFT LCD UART Display Module

15-Inch 1024×768 TFT LCD UART Display Module

High-Brightness IPS Medical-Grade Display with Integrated Cortex-M4 UART Control Board

As intelligent medical systems continue to evolve, the display is no longer just an information window — it is the core interface for precise operation and reliable monitoring.

This 15-inch 1024×768 TFT LCD UART display module integrates a high-brightness IPS panel, a powerful UART control board, and flexible touch options, delivering a stable, clear, and efficient human-machine interaction solution for medical and industrial applications.

1. Product Overview: Integrated High-Performance Display Solution

15-inch TFT-LCD display module is equipped with a professional UART control board. With a resolution of 1024×768 and brightness up to 750 cd/m², it ensures excellent visibility even under complex lighting conditions.

The IPS panel technology provides wide viewing angles and superior color consistency, making it ideal for medical monitoring equipment, diagnostic instruments, and HMI systems.

The module supports both capacitive touch (CTP) and optional resistive touch, allowing flexible configuration for different environments.

2. Core Technical Advantages

2.1 High-Brightness IPS Display for Clear and Accurate Imaging

• Resolution: 1024 × 768

• Brightness: 750 cd/m²

• Panel Technology: IPS wide viewing angle

• Active Area: 304.13 × 228.10 mm

The IPS structure ensures stable brightness and color consistency from multiple viewing angles — essential in medical diagnostic environments.

2.2 Cortex-M4 Based UART Control Board

The integrated UART board is built on a Cortex-M4 MCU core, offering strong processing capability and versatile interface support.

• Signal Input: LVDS

• Signal Output: UART (TTL / RS232 / RS485)

• Power Supply: 12V / 2A

• Flash Capacity: 128Mbit ~ 2×1GB

This control solution enables fast data transmission and stable communication, making system integration more efficient and reliable.

2.3 Flexible Touch Options

• Standard: Capacitive Touch Panel (CTP)

• Optional: Resistive Touch

Capacitive touch provides responsive multi-touch interaction, while resistive touch is suitable for glove operation or special industrial environments.

3. Structural Design & Environmental Reliability

The compact structural design allows easy integration into medical and industrial systems. The wide operating temperature range ensures long-term stability under demanding conditions.

4. Application Areas: Smart Medical Systems

This display module is widely used in:

• Medical monitoring devices

• Diagnostic and analytical equipment

• Medical testing terminals

• Intelligent treatment systems

• Self-service medical kiosks

The combination of high resolution and high brightness ensures clear data visualization, improving operational precision and patient safety.

5. Key Specifications Summary

• ✅ Screen Size: 15 inch

• ✅ Resolution: 1024 × 768

• ✅ Brightness: 750 cd/m²

• ✅ Viewing Angle: IPS

• ✅ Signal Input: LVDS

• ✅ Signal Output: UART TTL / RS232 / RS485

• ✅ Power Supply: 12V / 2A

• ✅ Touch Panel: CTP (Resistive optional)

• ✅ Operating Temperature: -20°C to +70°C

• ✅ Storage Temperature: -30°C to +80°C

Why Choose This 15-Inch UART Display Module?

✔ High-brightness IPS panel for complex lighting environments
✔ Cortex-M4 based control board for stable performance
✔ Multiple communication interfaces for flexible integration
✔ Medical-grade reliability
✔ Customizable Flash capacity and touch solutions

If you are looking for a high-brightness, stable, and scalable 15-inch medical-grade display solution, this 1024×768 TFT LCD UART module is an ideal choice.

For more technical details or customization support, feel free to leave a message or contact us for the full specification and development assistance.

Why Choose DINGTouch?

DINGTouch is a professional manufacturer specializing in LCD displays and capacitive touch screens with over 10 years of R&D and production experience.

Our Advantages

• Complete supply chain: display + touch + optical bonding

• Customizable solutions for OEM/ODM

• Stable long-term mass production

• Rich application experience across global markets

• Professional engineering support

Whether you need standard modules or fully customized solutions, DINGTouch helps you shorten development cycles and improve product competitiveness.

Technical Specifications Overview

Get a Customized Solution Today

If you’re looking for a high-quality, long-life 15-inch IPS display for industrial or commercial applications, DINGTouch provides the most reliable and flexible solution.

Contact us for specifications, samples, or custom development today!
